XBee USB Serial Converter
by
DrYerzinia.
2
layer board of
1.31x1.76
inches
(33.27x44.73
mm).
Shared on
August 31st, 2013 02:12.
Control XBee Tranciver from via USB. More details on my site
RS485iso
by
FortConsulting.
2
layer board of
2.39x3.75
inches
(60.66x95.25
mm).
Shared on
August 30th, 2013 23:06.
isolated rs485/DMX splitter
not tested yet and really hoping that the first run here still works as I forgot the bypass caps requested by the data sheet. Thus improvement is welcome, but probably not bad for a first ever board. uses optoisolators and dc-dc converters to galvanicly and optically isolate 4 output buses from one input bus and each other.
uses MAX488 trancievers, 6n137 optos, and RI-0505S DC-DC converters by recom power.
Mini leafSupply
by
nathanpc.
2
layer board of
2.05x1.45
inches
(52.07x36.83
mm).
Shared on
August 30th, 2013 22:55.
A mini version of the leafSupply power supply
Ffc Breakout V1.3
by
metsfan.
2
layer board of
0.53x1.53
inches
(13.36x38.76
mm).
Shared on
August 30th, 2013 00:09.
FFC Breakout
FT817USB
by
DrYerzinia.
2
layer board of
2.11x1.77
inches
(53.62x44.98
mm).
Shared on
August 29th, 2013 08:12.
Circuit board to transmit with my Yaesu FT817 radio via USB port for code, bom, and other details look on my site
