12x WS2812 - RGB LED board
by
slgonzalez.
2
layer board of
3.99x0.60
inches
(101.27x15.24
mm).
Shared on
August 7th, 2013 20:33.
12 WS2812 RGB LEDs with supporting capacitors and resistors. Has .1" 3-pin header.
Sample board 2.25 X 2.25
by
NsN.
2
layer board of
0.89x0.89
inches
(22.50x22.50
mm).
Shared on
August 7th, 2013 17:21.
A small sample board to compare different board colours and thickness
Light Controller
by
millers.
2
layer board of
2.32x2.38
inches
(59.00x60.48
mm).
Shared on
August 7th, 2013 00:29.
TLC5940 connections
S Node V0.01
by
rmhome.
2
layer board of
0.89x1.50
inches
(22.56x38.10
mm).
Shared on
August 6th, 2013 23:07.
Atmega 328 and NRF24 radio module acting as a sensor node - data is sent to a raspi and uploaded to web. www.rmhome.co.uk/pi twitter:@rm83
chordite v0.5
by
sloev.
2
layer board of
2.49x2.65
inches
(63.17x67.31
mm).
Shared on
August 6th, 2013 19:40.
one hand keyboard
