OSH Park
Shared projects
TEST shared project
by
fustini.
2
layer board of
6.30x1.29
inches
(160.12x32.69
mm).
Shared on
May 26th, 2017 22:45.
Prototyping_PCB.kicad_pcb
source: https://github.com/Drc3p0/Prototyping_Workshop
Grasshopper.v01h
by
PeskyProducts.
4
layer board of
0.71x1.76
inches
(17.93x44.73
mm).
Shared on
May 26th, 2017 20:00.
Breakout for Murata (CMWX1ZZABZ) module with STM32L082 + SX1276. Changed pinout to conform to nRF52832 add-on board designed for Butterfly to allow OTA of STM32L082 firmware via BLE using flow-control on UART1.
BCM847 DIP-6 breakout board
by
Oiseaux.
2
layer board of
0.42x0.52
inches
(10.69x13.23
mm).
Shared on
May 26th, 2017 19:18.
Converts BCM847 SMD matched pair NPN to (obsolete) LM394 dip-6 pinout (CBE-EBC). For analog synth projects. Includes slot for Tempco.
serial to ttl.kicad_pcb
by
kg5iyl.
2
layer board of
1.21x0.71
inches
(30.63x17.93
mm).
Shared on
May 26th, 2017 00:26.
Dual TTL logic to RS-232 logic converter using MAX3222E or identical pinout on PDIP-18
nRF52832_ButterflyAddOn.v01
by
PeskyProducts.
2
layer board of
0.71x0.71
inches
(17.93x17.93
mm).
Shared on
May 25th, 2017 22:01.
BLE add-on for Butterfly and Dragonfly for OTA firmware updates, UART bridge for wireless data transfer using standard Nordic UART Service with hardware flow control to increase speeds to ~5 kbps. Allows update of STM32L4 host firmware wirelessly via BLE.
