Pinguino_SMD-4550.kicad_pcb V2.1.
by
fandres.
2
layer board of
1.01x1.01
inches
(25.55x25.55
mm).
Shared on
May 27th, 2017 02:06.
PCB in surface mount of the Pinguino board based on the microcontroller PIC18F4550 V2.1.
PCB-Based CCW Pancake Coil
by
Dog-One.
2
layer board of
3.39x3.39
inches
(86.16x86.16
mm).
Shared on
May 27th, 2017 00:11.
PCB-Based CW Pancake Coil
by
Dog-One.
2
layer board of
3.39x3.39
inches
(86.16x86.16
mm).
Shared on
May 27th, 2017 00:04.
PCB-Based Bifilar Pancake Coil
by
Dog-One.
2
layer board of
3.39x3.39
inches
(86.16x86.16
mm).
Shared on
May 26th, 2017 23:57.
AN3813K BLDC VCR Cylinder Motor Driver Arduino Shield
by
dewhisna.
2
layer board of
2.11x2.73
inches
(53.49x69.37
mm).
Shared on
May 26th, 2017 22:52.
AN3813K Brushless DC Motor Driver Arduino Shield for use with VCR Cylinder Motors with precision speed control with feedback.
Specifically designed to be used with the Arduino ProMini PiDuino HAT and the STM32F746G Discovery Board, but can also be used on any Arduino Uno R3 compatible target. Supports both 5V and 3.3V logic with on-board level-shifters.
