Teensy_temp.brd
by
Vinay28.
2
layer board of
0.82x2.02
inches
(20.75x51.21
mm).
Shared on
May 27th, 2017 21:14.
Single-to-Dual Voltage Converter
by
dewhisna.
2
layer board of
0.96x1.21
inches
(24.28x30.63
mm).
Shared on
May 27th, 2017 18:04.
Simple 555 charge-pump circuit to create a negative tracking split supply voltage that mirrors the single supply input voltage.
VIC_Circuit_Production(12-20-2011).brd
by
SecureSupplies.
2
layer board of
6.78x3.59
inches
(172.08x91.14
mm).
Shared on
May 27th, 2017 08:31.
TW Stan Meyers VIC
F7-AlienFlightNG-Quad-Brushed-V1.zip
by
AlienFlightNG.
2
layer board of
1.10x1.26
inches
(28.02x32.00
mm).
Shared on
May 27th, 2017 07:13.
BRAT rev 1
by
osok.
2
layer board of
1.40x3.13
inches
(35.56x79.45
mm).
Shared on
May 27th, 2017 02:17.
Badge Reader Active Tap : allows man in the middle, recording and replaying wiegand traffic.
