OSH Park
Shared projects
Relay Bypass 3.2.1
by
plesur.
2
layer board of
2.39x0.61
inches
(60.66x15.57
mm).
Shared on
August 15th, 2014 11:29.
Slightly narrower relay bypass board
VL6180XProximitySensorBreakOutBoard.v01
by
PeskyProducts.
2
layer board of
0.71x0.31
inches
(17.98x7.80
mm).
Shared on
August 15th, 2014 05:32.
Breakout board for ST Microelectronics' VL6180X proximity sensor for breadboarding with Teensy and Arduino. VIN is between 3 and 5.5 V. Sensor uses laser range finding (!) to detect absolute distances independent of surface reflectance up to 10 cm away or more depending on ambient lighting. Can be used to recognize hand gestures for sophisticated touchless micro-controlling. Small package, low cost, and low power usage makes integrating into existing projects, or use as a Teensy 3.1 or Arduino Pro Mini add-on board very attractive. Does it work as advertised?
ATMEGA168 programmer
by
DaveWerld.
2
layer board of
2.39x1.20
inches
(60.66x30.48
mm).
Shared on
August 14th, 2014 23:41.
Programming converter for DIP ATMEGA
Sonde2
by
RussNelson.
2
layer board of
2.45x3.22
inches
(62.23x81.79
mm).
Shared on
August 14th, 2014 22:00.
Read a pH, conductivity, and DO proble.
RetroCell v1
by
sideburn.
2
layer board of
2.31x1.85
inches
(58.72x46.99
mm).
Shared on
August 14th, 2014 21:49.
Rotary Phone Controller
