OSH Park
Shared projects
Reflow oven Controller
by
Crusader68.
2
layer board of
3.94x1.97
inches
(100.00x50.01
mm).
Shared on
August 13th, 2014 07:12.
0xpit’s reflow oven controller
Solder Station shield for RT tips
by
Crusader68.
2
layer board of
2.25x2.17
inches
(57.02x55.02
mm).
Shared on
August 13th, 2014 07:11.
An Arduino compatable shield that allows you to control the temp of a Weller RT1 tip(wmrp handle isnt needed as RT tips house the heater and temp sensor)
Risenfall LED Driver
by
dustmason.
2
layer board of
3.19x1.55
inches
(80.95x39.37
mm).
Shared on
August 13th, 2014 04:45.
MAX21100+LIS3MDL+MS5637TeensyAdd-On.v01
by
PeskyProducts.
2
layer board of
0.71x0.51
inches
(17.93x12.83
mm).
Shared on
August 13th, 2014 04:42.
MAX21100 6-axis gyro/accelerometer motion sensor plus LIS3MDL 3-axis magnetometer plus MS5637 24-bit pressure sensor. This board can be a Mini Add-On shield for Teensy 3.1 or a standalone breakout board for Arduino breadboard use. Solder jumpers on the back change the source of power to make it breadboard friendly. The board is hardwired for I2C since the pressure sensor is I2C only. The MAX21100 reads data from the magnetometer slave as an I2C master and performs 9 DoF sensor fusion in hardware with quaternions or AHRS heading as output by direct register read. This is what the Invensense MPU9250 DMP should have been; maybe Maxim Integrated got it right?
MIC_PREAMP
by
USBtoROS_Connector.
2
layer board of
1.01x1.01
inches
(25.68x25.68
mm).
Shared on
August 13th, 2014 00:58.
5V preamp for OMAP5
