OSH Park
Shared projects
TIP31Board
by
el3kim.
2
layer board of
1.46x1.75
inches
(37.16x44.45
mm).
Shared on
August 12th, 2014 22:36.
RGB Led strip Arduino PWM controller
AS5311 Encoder Module, Rev 2
by
msds.
2
layer board of
1.04x1.30
inches
(26.34x33.02
mm).
Shared on
August 12th, 2014 22:26.
See sorens.in/posts/2014-8-12-linear-encoder for documentation. Board is released under CC Attribution-ShareAlike 4.0 International.
AMS Encoder Module
by
msds.
2
layer board of
1.04x1.30
inches
(26.34x33.02
mm).
Shared on
August 12th, 2014 21:05.
DO NOT USE! DEFECTIVE! BAD! WRONG! See revision two for a fixed version.
QC20 charger
by
MTT727.
2
layer board of
2.36x1.54
inches
(60.02x39.01
mm).
Shared on
August 12th, 2014 20:02.
USB charger and audio pass through
DarlingtonDriverBdRevB
by
DevilTech-Team1559.
2
layer board of
2.00x1.00
inches
(50.80x25.43
mm).
Shared on
August 12th, 2014 20:00.
FRC Compatible 12/24V Driver Bd.
