RC-USB-JOYSTICK
by
irun4fundotca.
2
layer board of
1.75x1.16
inches
(44.40x29.46
mm).
Shared on
December 29th, 2013 21:13.
RC-USB Joystick Interface
More info:
http://www.rcgroups.com/forums/showthread.php?t=508122
Schematic:
http://static.rcgroups.net/forums/attachments/2/2/0/9/8/a807626-127-Schematic.jpg
Source files:
http://www.rcgroups.com/forums/showatt.php?attachmentid=804405&d=1145646873
Lightning Sensor for Arduino w/ Break Away Antenna
by
2
layer board of
1.22x0.68
inches
(30.99x17.27
mm).
Shared on
December 29th, 2013 07:39.
Arduino compatible lightning sensor board that uses the Franklin AS3935 IC.
C1: 10 uF C2: 1uF C3: 1uF C5: 100pF C6: 1nF
R1: 10k R2: 10k R3: current limiting resistor for LED
L1: MA5532-AE
Use the open source arduino sketch “Striker” (found online) and change the default I2C address to 0x03.
LCDuino Shield Adapter
by
nsayer.
2
layer board of
2.70x2.10
inches
(68.58x53.37
mm).
Shared on
December 29th, 2013 04:54.
Connect LCDuino to Arduino Uno shields
FET Shield for FRDM-KL25Z
by
icenyne.
2
layer board of
1.89x2.06
inches
(48.03x52.20
mm).
Shared on
December 28th, 2013 19:27.
This shield for the FRDM-KL25Z allows controlling 18 SOT-23 FETs to pull down external non-inductive loads. It was originally designed to drive two large 7-segment displays and a DSLR for a photo booth application. The control function has since been moved to an i.MX6Q Sabre SD board…
MIDI connector - MOUNT
by
Arno.
2
layer board of
1.06x0.27
inches
(26.92x6.76
mm).
Shared on
December 27th, 2013 22:52.
Mount your DIN5 connector using these small PCB strips. One of these boards is good for 2 connectors (otherwise the board would be too small for OSH Park to process).
Also see MIDI connector - BREAK OUT.
PS: I’ve used these boards with connectors similar to Sparkfun PRT-09536 (MIDI Connector - Female Right Angle).
