OSH Park
Shared projects
Power Module
by
proskate44.
2
layer board of
1.75x1.00
inches
(44.40x25.40
mm).
Shared on
December 11th, 2013 05:13.
Small AC/DC converter block
Traffic Light
by
proskate44.
2
layer board of
3.30x1.10
inches
(83.77x27.94
mm).
Shared on
December 11th, 2013 05:12.
Traffic Light Controller Module
HELEDD rev. B
by
nocko.
2
layer board of
1.50x1.50
inches
(38.10x38.10
mm).
Shared on
December 11th, 2013 02:50.
Arduino clone w/ sensors, designed for implantation.
http://heledd.googlecode.com//
TTL Logic Probe Slim
by
kuashio.
2
layer board of
4.21x1.21
inches
(106.86x30.71
mm).
Shared on
December 11th, 2013 01:48.
A very simple TTL logic probe for teaching
LED stick connector triangle
by
Zephod.
2
layer board of
0.67x0.58
inches
(16.92x14.66
mm).
Shared on
December 11th, 2013 01:19.
Configurable WS2812b LED Stick connector triangle with optional center LED.
