Mightyboard RevE
by
RossRobotics.
2
layer board of
6.03x4.69
inches
(153.14x119.15
mm).
Shared on
October 22nd, 2013 22:03.
Replicator Mightyboard RevE
Usb Breadboard Adapter
by
Duke.
2
layer board of
0.73x0.46
inches
(18.57x11.68
mm).
Shared on
October 22nd, 2013 19:54.
Usb adapter includes diodes and resistors allowing direct routing to AVR pins.
LiquidPixel Rev. A "mPix"
by
cwoodall.
2
layer board of
0.70x0.45
inches
(17.88x11.53
mm).
Shared on
October 22nd, 2013 18:41.
A tiny W2812 breakout board.
Note that at the moment this is untested, but likely to work.
SOT23 Socket DIP Adapter
by
Duke.
2
layer board of
0.72x0.92
inches
(18.31x23.39
mm).
Shared on
October 22nd, 2013 14:05.
CILightsDIP
by
tester.
2
layer board of
1.33x2.08
inches
(33.86x52.93
mm).
Shared on
October 22nd, 2013 12:39.
Continuous Integration Lights DIP version
