CounterBoard 1.0
by
Hustin13.
2
layer board of
2.54x1.35
inches
(64.47x34.29
mm).
Shared on
October 22nd, 2013 03:33.
12-bit pulse counter. Designed for counting the pulses of a 12V input signal (IN pin). All other pins are 0 to 5V.
LEDStatusIndicator
by
patopop007.
2
layer board of
0.91x1.04
inches
(23.04x26.39
mm).
Shared on
October 21st, 2013 15:28.
Handy device that you can use to inform people outside your dorm on whether you are available, working, sleeping, or in need of solitude.
You can check out the source and pictures of the final product at Github
PEC16 edge
by
uChip.
2
layer board of
0.70x0.80
inches
(17.78x20.32
mm).
Shared on
October 21st, 2013 02:27.
Rotary Encoder Breakout Boards
See my project on GitHub for details, latest versions and links to code.
SNES Tototek Adapter SMD
by
Helder.
2
layer board of
1.00x1.44
inches
(25.40x36.50
mm).
Shared on
October 20th, 2013 04:09.
SSRneon G2 LED
by
pmscientist.
2
layer board of
2.76x2.18
inches
(70.00x55.40
mm).
Shared on
October 19th, 2013 19:30.
SSRneon G2 LED AC SSR from DIYC
