OSH Park
Shared projects
MCP4922 Breakout V1.0
by
chipaudette.
2
layer board of
0.94x1.25
inches
(23.83x31.75
mm).
Shared on
September 3rd, 2013 02:27.
Breakout for MCP4922 2-channel, 12-bit DAC
Raspberry Pi - PSU - Rev 2
by
gamaral.
2
layer board of
2.00x2.00
inches
(50.80x50.80
mm).
Shared on
September 3rd, 2013 00:05.
More Information: http://guillermoamaral.com/read/rpi-psu-r2
GitHub Repository: https://github.com/gamaral/rpi-pwrbtn
Disclaimer: This board is licensed under the CERN OPEN HARDWARE LICENSE. Use at your own risk.
RFID-1
by
duckythescientist.
4
layer board of
1.40x2.50
inches
(35.56x63.50
mm).
Shared on
September 2nd, 2013 20:37.
Impinj R2000 reader board
ISPduino
by
CryoArchive.
2
layer board of
2.00x1.33
inches
(50.80x33.81
mm).
Shared on
September 2nd, 2013 13:19.
Arduino based prototyping board
UsbAmps R [B]
by
jmedved.
2
layer board of
2.13x0.91
inches
(54.15x23.16
mm).
Shared on
September 2nd, 2013 02:25.
UsbAmps is a small USB pass-through device that measures current, voltage and power used by whatever is connected on its output.
