OSH Park
Shared projects
Generic MOSFET LVD w/ terminals
by
austindavid.
2
layer board of
1.25x1.10
inches
(31.78x27.94
mm).
Shared on
November 6th, 2016 23:30.
updated LVD with screw terminals
Generic MOSFET LVD, update
by
austindavid.
2
layer board of
1.25x1.25
inches
(31.78x31.78
mm).
Shared on
November 6th, 2016 23:16.
moved the ground plane and rerouted a +ve line to avoid shorting
Turris Omnia GPS
by
kolaCZek.
2
layer board of
0.68x1.89
inches
(17.15x47.96
mm).
Shared on
November 6th, 2016 21:34.
DerKnopf LED ring
by
hzeller.
2
layer board of
1.19x1.26
inches
(30.20x32.00
mm).
Shared on
November 6th, 2016 21:32.
IR receiver and charlieplexed LED ring around volume control. Used in https://github.com/hzeller/DerKnopf but can be useful for other things as well. 6-wire charlieplexing for 30 LEDs, lined up exactly with 1/32 turn for 32-detent encoder; two spacing.
14226^4
by
epccs.
2
layer board of
2.38x2.10
inches
(60.33x53.37
mm).
Shared on
November 6th, 2016 20:28.
RPUadpt
Shield for full duplex RS-422 over CAT5. Its a multidrop bus that works with serial bootloaders (e.g. optiboot, xboot… ) and avrdude.
