atmega328_esp8285.kicad_pcb
by
mal.
2
layer board of
1.02x2.28
inches
(26.04x58.01
mm).
Shared on
April 2nd, 2017 09:21.
[OBSOLETE] Charlie's AlienWhoop F4
by
AlienWhoop.
2
layer board of
1.14x1.14
inches
(29.01x29.01
mm).
Shared on
April 2nd, 2017 09:04.
[This version of the project is obsolete. Please use the following link to order the latest board: https://oshpark.com/projects/NCDk9MaM ]
AlienFlight F4 remixed for Tiny Whoop/Inductrix.
Note: Best with the 2oz 0.8mm PCB
MIDI Button Controller
by
WayfarerAM.
2
layer board of
1.24x2.77
inches
(31.39x70.26
mm).
Shared on
April 2nd, 2017 08:14.
20 Button MIDI controller using shift registers.
USBDM_SWD_SER_JS16CWJ V3.5
by
pgo.
2
layer board of
1.63x1.78
inches
(41.48x45.26
mm).
Shared on
April 2nd, 2017 05:55.
USBDM BDM for
- Kinetis (SWD)
- HCS08
- HCS12
- CFV1
Documentation available at Sourceforge.
Software information available at Sourceforge.
Design files available at GitHub.
USB Isolator 2
by
_djdt_.
2
layer board of
1.58x0.89
inches
(40.16x22.66
mm).
Shared on
April 2nd, 2017 04:06.
USB isolator
| Part No. | Value |
|---|---|
| U1 | ADUM4160 |
| U2 | CRE1S0505S3C |
| R1-4 | 24R |
| C1-4 | 0u1 |
| C5 | 1u |
| C6 | 10u |
| L1,2,4,5 | Ferrite Bead |
| L3 | 10u (Panasonic G) |
R9 and D1 are only needed if indicator required
Bridge both FS or both LS pads with solder / 0R 0402 to set full or low speed modes
