Shared projects
punchy-v1
by
kevinkrieger.
2
layer board of
1.41x0.65
inches
(35.92x16.61
mm).
Shared on
April 1st, 2017 00:56.
An mpu6050 built to be attached to a punching glove and connected via Bluetooth to a smartphone.
Pool Controller v2.1
by
osmosis.
2
layer board of
2.65x2.74
inches
(67.31x69.52
mm).
Shared on
March 31st, 2017 20:22.
Cloud-based pump speed, solar collector controls, and temperature monitoring for your pool.
More information on the GitHub Project Page
Ver2.0.brd
by
Pklein25.
2
layer board of
0.53x0.69
inches
(13.46x17.48
mm).
Shared on
March 31st, 2017 17:05.
PCB for connecting an op-amp to a 6 position header
tps709-breadboard-adapter
by
mh21.
2
layer board of
0.31x0.34
inches
(7.77x8.66
mm).
Shared on
March 31st, 2017 15:16.
TPS709xx breadboard adapter based on the reference design of the TI datasheet.
KiCAD Schematics and PCB layout can be found on GitHub.
breadboard-level-shifter
by
mh21.
2
layer board of
0.40x0.50
inches
(10.21x12.75
mm).
Shared on
March 31st, 2017 15:12.
4x breadboard level shifter similar to Sparkfun #12009 and Adafruit #757.
Details: NXP app note AN10441
KiCAD Schematics and PCB layout can be found on GitHub.
