OSH Park
Shared projects
OMSI
by
hydronics.
2
layer board of
2.10x3.09
inches
(53.34x78.44
mm).
Shared on
August 19th, 2014 06:42.
Zoo in You - Handwashing
PIDDYBOT_V4_BT_Final
by
IHPArchives.
2
layer board of
1.89x2.95
inches
(47.96x75.01
mm).
Shared on
August 19th, 2014 06:12.
PIDDYBOT with BLUETOOTH!
XMEGA A1 Breakout
by
the-hat.
2
layer board of
1.01x4.31
inches
(25.55x109.40
mm).
Shared on
August 19th, 2014 03:54.
USB, voltage regulator, and breakout board for AVR XMEGA A1 series MCU
Bill of materials: http://noxvault.org/misc/xmega-a1-breakout-r2.csv
ATXMEGAxxxE5 Breakout
by
the-hat.
2
layer board of
0.91x1.81
inches
(23.11x45.97
mm).
Shared on
August 19th, 2014 03:45.
ATXMEGAxxxE5 Breakout
Bill of materials: http://noxvault.org/misc/xmega-e5-breakout.csv
Shaft encoder breadboard breakout
by
KO4XL.
2
layer board of
0.89x0.70
inches
(22.56x17.78
mm).
Shared on
August 19th, 2014 03:35.
For Alps shaft encoder w/ pushbutton or similar
