OSH Park
Shared projects
onion2 breakout
by
washintonian88.
2
layer board of
1.57x2.05
inches
(39.78x51.97
mm).
Shared on
March 12th, 2017 14:28.
OBSOLETE! PLEASE SEE GIT PAGE FOR REV 2
Link for REV 2 - https://oshpark.com/shared_projects/nRecWv9b
~~ Onion Omega 2 Dock - Rev 1 ~~
The goal for this dock is to allow for ‘simple’ bread boarding of the onion omega 2 boards. I have included a 5v to 3.3v voltage regulator for power and a CH340G usb to serial IC for communications. Communications and power are provided through the micro USB connector and the regular USB connector is to provide access to the onion’s USB line.
Files can be found on my github ( https://github.com/washingtonian88/onion2-breakout)
ESP8266-DS18B20-breakout-3-12-17.brd
by
M0J001.
2
layer board of
0.66x1.02
inches
(16.81x26.04
mm).
Shared on
March 12th, 2017 14:09.
For use with ESP8266-1, 3.3v 1117 smd regulator, 0.1uF bypass capacitor, 4.7k resistor, and 3 ds18B20 temperature sensors.
IR Remote + Temp + Light Sensor (ESP based) - 0.1 alpha
by
takigama.
2
layer board of
2.70x1.27
inches
(68.66x32.16
mm).
Shared on
March 12th, 2017 13:46.
Designed with mqtt and homie in mind.
see This link
Haven’t written the code for it yet
BPi-CAN.kicad_pcb
by
bertc3p0.
2
layer board of
3.94x3.94
inches
(100.15x100.15
mm).
Shared on
March 12th, 2017 10:01.
Banana PI CAN Interface V1.5
http://lnxpps.de/bpie
90° Turn v5.2.3
by
Gunderson.
2
layer board of
1.10x1.10
inches
(27.94x27.94
mm).
Shared on
March 12th, 2017 04:52.
5-pin 90° turn for interfacing boards in packages that benefit from flat array layouts.
v5.2 adds more breathing room around pins for boards that have up to 0.1" margins
