Midio
by
feurig.
2
layer board of
3.26x1.13
inches
(82.70x28.58
mm).
Shared on
September 16th, 2013 12:14.
3.3v or 5v Midi interface
stepmonster
by
feurig.
2
layer board of
3.19x1.25
inches
(80.95x31.75
mm).
Shared on
September 16th, 2013 12:14.
Power Board for a unipolar stepper motor
EPM7032_test_board
by
basis108.
2
layer board of
2.35x1.67
inches
(59.64x42.42
mm).
Shared on
September 16th, 2013 05:36.
Altera EPM7032 CPLD test board
RC Winch Controller
by
laneboysrc.
2
layer board of
0.87x1.08
inches
(22.05x27.43
mm).
Shared on
September 15th, 2013 10:52.
A FET controller for a 1/10 scale RC car winch.
See http://laneboysrc.blogspot.com/2013/09/make-your-own-rc-winch-controller.html for more information.
Firmeare, schematics and layout files are available at https://github.com/laneboysrc/rc-winch-controller
YouTube video: http://youtu.be/_9bI9k0ff98
Xeno-GC Clone
by
gamaral.
2
layer board of
1.29x1.70
inches
(32.69x43.18
mm).
Shared on
September 15th, 2013 07:02.
GameCube modchip.
Schematic and Board files are available on GitHub.
Disclaimer: This board is licensed under the CERN OPEN HARDWARE LICENSE. Use at your own risk.
