OSH Park
Shared projects
poker hands
by
matthewphilyaw.
2
layer board of
2.05x1.78
inches
(52.12x45.11
mm).
Shared on
September 19th, 2013 15:42.
poker hand kata
Xeno-GC Clone - Rev 03
by
gamaral.
2
layer board of
0.70x1.20
inches
(17.78x30.48
mm).
Shared on
September 19th, 2013 15:30.
GameCube modchip.
Schematic and Board files are available on GitHub.
Disclaimer: This board is licensed under the CERN OPEN HARDWARE LICENSE. Use at your own risk.
CoolRunner-II Breakout v0.1
by
kmod.
2
layer board of
1.09x1.28
inches
(27.76x32.54
mm).
Shared on
September 19th, 2013 09:24.
Minimalist breakout for a small+cheap Xilinx CPLD. http://blog.kevmod.com/2013/09/cplds-prototype-and-breakout/
USB Tiny MKII Slim
by
adrian_pl.
2
layer board of
2.66x0.87
inches
(67.64x22.07
mm).
Shared on
September 19th, 2013 07:49.
AVR Programmer. Project by manekinen (Poland)
Project site: http://mdiy.pl/programator-usbtiny-mkii-slim/ (in polish)
TPS7A4700 v1.2
by
bwshockley.
2
layer board of
1.58x0.79
inches
(40.00x20.02
mm).
Shared on
September 18th, 2013 18:40.
