SHF DCB110R

DC Block by SHF Communication Technologies
Download Datasheet Request Quote

Note : Your request will be directed to SHF Communication Technologies.

The SHF DCB110R from SHF Communication Technologies is a DC Block with 1.00 mm connectors that operates from DC to 110 GHz. It has an insertion loss of less than 1.5 dB and can handle up to 30 watts of input power with a voltage rating of 20 V. The SHF DCB110R measures 17 x 7 x 8 mm and is ideal for SATCOM, antenna measurements, data transmission, and optical communications.

Product Specifications

    Product Details

    • Part Number :
      SHF DCB110R
    • Manufacturer :
      SHF Communication Technologies
    • Description :
      Broadband DC Block from DC to 110 GHz

    General Parameters

    • Frequency :
      DC to 110 GHz
    • Insertion Loss :
      1 to 1.5 dB
    • Breakdown Voltage :
      20 V
    • Input Power (Avg) :
      30 W
    • Return Loss :
      10 to 20 dB
    • Dimension :
      17 x 7 x 8 mm
    • Connector :
      1 mm

    Temperature

    • Operating Temperature :
      10 to 50 Degrees C
