5. PiMPro Tower 1900
PiMPro Tower 1900 Image

PiMPro Tower 1900

PIM Analyzer by Communication Components Inc (20 more products)
Download Datasheet Request Quote

Note : Your request will be directed to Communication Components Inc.

The PiMPro Tower 1900 from Communication Components Inc is a PIM Analyzer with TX Frequeny 1.93 to 1.99 GHz, RX Frequency 1.87 to 1.91 GHz, Transmitter Freq. Accuracy < 5 ppm, Tx Carrier Power 24 to 46 dBm × 2 (250 mW to 40 W × 2), Transmitter Power Accuracy 0.3 dB. Tags: Portable. More details for PiMPro Tower 1900 can be seen below.

Product Specifications

    Product Details

    • Part Number :
      PiMPro Tower 1900
    • Manufacturer :
      Communication Components Inc
    • Description :
      1.93 to 1.99 GHz, Portable PIM Analyzer

    General Parameters

    • Type :
      Portable
    • Frequency Bands :
      PCS 1900
    • TX Frequeny :
      1.93 to 1.99 GHz
    • RX Frequency :
      1.87 to 1.91 GHz
    • Transmitter Freq. Accuracy :
      < 5 ppm
    • Tx Carrier Power :
      24 to 46 dBm × 2 (250 mW to 40 W × 2)
    • Transmitter Power Accuracy :
      0.3 dB
    • PIM Sensitivity :
      -135 dBm
    • Transmitter Reverse Pwr. Protection :
      13 dBm (20 mW) continuous
    • Measurements :
      PIM over Time, Noise Floor
    • AC Power :
      AC & DC (AC 90 - 256 V, 50 - 60 Hz)
    • Operating Temperature :
      -10 to 45 Degree C
    • Power Consumption :
      <340 W
    • Dimension :
      14 ×9 ×4.5 in. (350 × 230 × 114 mm)
    • Display :
      7" TFT Color Touch Screen
    • Battery :
      28 VDC
    • Connector :
      7/16 DIN, 7/16 DIN - Female
    • Storage Temperature :
      -30 to 60 Degree C

    Technical Documents
Click to view more product details on manufacturer's website  »
