6. 716007
716007 Image

716007

RFID Reader Module by GAO RFID (5 more products)
Download Datasheet Request Quote

Note : Your request will be directed to GAO RFID.

The 716007 from GAO RFID is an UHF RFID reader module that can be used with read/write RFID tags compliant with ISO18000-6B and EPC Class 1 Gen 2 ISO18000-6C protocols. It operates from 902 to 928 MHz and provides fast tag read/write operation with a high identification rate. The module supports various EPC lengths - 16, 32, 48, 64, 80 or 96 bits. This reader provides an output power of up to 30 dbm (adjustable) while operating over a single 5 V DC power supply. It is available in a package that measures 62 x 45 x 9 mm and is ideal for logistics, access control, attendance systems, anti-counterfeit and industrial production process control systems.

Product Specifications

    Product Details

    • Part Number :
      716007
    • Manufacturer :
      GAO RFID
    • Description :
      900 MHz UHF RFID Reader Module

    General Parameters

    • Application :
      Logistics, Anti-Counterfeiting, Attendance Systems, Access Control
    • Band :
      UHF
    • Frequency :
      902 to 928 MHz
    • Read/Write :
      Read/Write
    • Read Distance cm :
      100 cm
    • Read Distance :
      1000 mm
    • Write Distance :
      100 mm
    • Write Distance cm :
      10 cm
    • Output Power :
      30 dBm
    • Interface :
      TTL, RS232
    • Integrated Antenna :
      No
    • Protocol :
      EPC C1 Gen 2 ISO18000-6C /ISO18000-6B
    • Current :
      900 mA
    • Voltage :
      5 V
    • Package :
      Surface Mount
    • Dimensions :
      62 x 45 x 9 mm
    • Storage Temperaturee :
      -25 to 80 Degree C
    • Operating Temperature :
      -10 to 60 Degree C
