Mpu6000 Board
by
Janesak.
2
layer board of
0.95x0.70
inches
(24.13x17.78
mm).
Shared on
January 10th, 2014 06:35.
Breadboard Power Feeder
by
Eric.
2
layer board of
0.26x0.94
inches
(6.50x23.85
mm).
Shared on
January 10th, 2014 01:09.
Cost: $1.20 for three.
Description:
Small board to feed power from your bench supply to a solderless breadboard.
Install a 2x2 pin header at one end, on the bottom side. Solder wires at the other end (positive to square pad). Terminate wires with red and black banana plugs. Install this slide switch on the top side. Use a small zip-tie around the notches to provide wire strain relief.
Inductor tester var.JDB r0
by
chome.
2
layer board of
3.10x2.00
inches
(78.77x50.80
mm).
Shared on
January 9th, 2014 23:32.
Inductor tester var.JDB r0
PowerLED board V1
by
exuvo.
2
layer board of
5.91x0.79
inches
(150.16x20.14
mm).
Shared on
January 9th, 2014 19:03.
Board with 5st 1-2W PowerLEDs driven by a TLC59401 and controlled with a ATTINY24A.
Power Board V1
by
Mathurm.
2
layer board of
2.61x2.06
inches
(66.17x52.20
mm).
Shared on
January 9th, 2014 18:32.
dual output
