N9952A Image

N9952A

Antenna Analyzer by Keysight Technologies (4 more products)

Note : Your request will be directed to Keysight Technologies.

The N9952A (FieldFox Series) is a Handheld microwave analyzer operates from 300 kHz to 50 GHz and can be remote controlled via an iPad or iPhone. The standard model is a cable and antenna analyzer with optional VNA, spectrum analyzer, built-in power meter, and other options available. It can simultaneously measure all four S-parameters and make accurate spectrum measurements (± 0.5 dB) without the need of warming-up. The analyzer weighs only 3.2 Kg and is available with a 3 Year warranty.

Product Specifications

    Product Details

    • Part Number :
      N9952A
    • Manufacturer :
      Keysight Technologies
    • Description :
      50 GHz Microwave Handheld Microwave Analyzer

    General Parameters

    • Applications :
      SATCOM, Backhaul, Military, Radar
    • Equipment Type :
      Handheld Analyzer
    • Weight :
      7.1 lbs
    • Dynamic Range :
      100 dB
    • Frequency :
      50 GHz
    • Output Power :
      -55 to -35 dBm
    • Note :
      Optional: VNA, Spectrum Analyzer, built-in Power Meter

    Technical Documents

Click to view more product details on manufacturer's website  »
