SNES RGB Bypass Board Vers. 4.1a with S-Video
by
borti4938.
2
layer board of
1.23x0.81
inches
(31.14x20.65
mm).
Shared on
February 13th, 2017 07:52.
RGB-Bypass for the SNES (Version 4a with S-Video) using a THS7373 or THS7374. This board is intend to use with the SNES Mini / Jr. if you want to have S-Video at the MultiAV, too.
Order this board with a substrate thickness of 0.8mm!
See GitHub for details.
SNES RGB Bypass Board Vers. 4.1b
by
borti4938.
2
layer board of
0.89x0.72
inches
(22.71x18.26
mm).
Shared on
February 13th, 2017 07:52.
RGB-Bypass for the SNES (Version 4b) using a THS7314, THS7316, THS7373 or THS7374.
Order this board with a substrate thickness of 0.8mm!
See GitHub for details.
sd2snes RevH extension board
by
borti4938.
2
layer board of
0.68x0.41
inches
(17.15x10.41
mm).
Shared on
January 26th, 2017 08:46.
Use substrate thickness of 0.8mm!
Look on GitHub for design files and installation pictures :)
SNES RGB Bypass Board V.4b
by
borti4938.
2
layer board of
0.93x0.72
inches
(23.52x18.26
mm).
Shared on
October 18th, 2016 07:19.
RGB-Bypass for the SNES using a THS7374. See GitHub for details.
